TSB-01
Surface temperature sensor
The surface temperature sensor is ideal for recording installation temperatures and temperature balances.
- No moving parts
- Measurement single pixel width 25 cm
- Measuring width approx. 13m (height 3.8m) when used on a Paver
- Measuring angle 120°
- Measuring range -50…300° C
- Protection category IP69k
- Operating temperature -40…85° C
- WxHxD: 94x80x28 mm
Detailed information
The surface temperature sensor is ideal for recording installation temperatures and temperature balances. As part of the PAVE Navigator, it is optionally attached to the end of a Paver’s sensor carrier and measures the freshly laid asphalt surface behind the screed.
Special features:
- No moving parts
- Measurement single pixel width 25 cm
- Measuring width approx. 13m (height 3.8m) when used on a Paver
- Measuring angle 120°
- Measuring range -50…300° C
- Protection category IP69k
- Operating temperature -40…85° C
- WxHxD: 94x80x28 mm
Area of application:
- Mobile machinery
- Road construction (e.g. on a Paver behind the screed)
TSB-01:
| Overall dimensions | (W/H/D) 94 mm x 28 mm x 80 mm |
| Housing / protection category | Aluminum housing, protection category IP69 (DIN EN 60529) |
| Weight | approx. 0,35 kg |
| Connections | Built-in plug 5pin. M12 |
| Power supply, power consumption | UB = 8..32 V (reverse polarity protected), approx. 40 mA at 12 V |
| Sensor | Field of view: 120°x10° Measuring range: -50°C to 300° C Accuracy: ±1°C (TObject = TUmgeb. = 0..50° C) ±2.5°C (TObject = 150°CTUmgeb. = 50° C) |
| Signal transmitter | 1x optical signal transmitter (housing LED) |
| Interfaces | 1x CAN (maximum baud rate: 1 Mbit/s) |
| Operating temperature range | -40..85° C (housing temperature) |
| EMC | Road vehicles: – Directive 2014/30/EU – UN/ECE-R10 – ISO 10605 – ISO 7637-1 – ISO 7637-2 – ISO 7637-3 Construction machinery: – DIN EN 13309 Industrial use: – DIN EN 61000-6-2 – DIN EN 61000-6-4 |
| Mechanical, climatic resilience | Cold: – DIN EN 60068-2-1 Dry heat: – DIN EN 60068-2-2 Vibration: – DIN EN 60068-2-6 Thermal shock: – DIN EN 60068-2-14 Shock: – DIN EN 60068-2-27 Continuous shock: – DIN EN 60068-2-27 Moist heat: – DIN EN 60068-2-30 Shocks due to rough handling: – DIN EN 60068-2-31 |
TSB-01 in mm
